DotView Glass
1 / 5
Bullet Proof Glass, also known as Bullet Resistant Glass, Armored Glass, or Ballistic Glass, is a high-strength optically transparent material designed to resist penetration upon impact. It is constructed using a specialized combination of two or more types of glass layered with polycarbonate and thermoplastic laminates.
All products are manufactured in accordance with Standard GA165-1997 and certified by national technical experts, ensuring top-tier safety for various security applications.
| Specification | Details |
|---|---|
| Product Name | Laminated Bullet proof Glass |
| Interlayer Thickness | 0.38mm to 2.28mm |
| Glass Thickness | 7mm - 75mm |
| Maximum Size | 2440mm * 7000mm |
| Minimum Size | 100mm * 100mm |
| Color Options | Clear, Ultra Clear, Grey, Bronze, Blue, Green, etc. |
| Standards | GA165fj79 / USA NIJ / European Standards |
| Glass Thickness | Surface Density | Ballistic Performance | Transparency |
|---|---|---|---|
| 13mm | 25kg/sqm | 51 type bullet, high speed chips | 80% |
| 18mm | 35kg/sqm | 51 type bullet | ≥ 70% |
| 30mm | 63kg/sqm | 7.62*39mm MSC | 60-70% |
| 35mm | 75kg/sqm | 7.62*54mm MSC | 60-70% |
| 45mm | 95kg/sqm | 5.8mm MSC | 60-70% |
| 60-70mm | 125-150kg/sqm | 7.62*39mm API | 60-70% |
Bullet Proof Glass is essential for high-security environments where protection of life and precious property is a priority:
We ensure maximum safety during transit using export-grade materials:
